Volume control damper kit

The variable volume control damper kit offers you a wide range of applications. Thanks to aluminium cog wheels the VCD is characterized by high stability and a long service life.

Mounting recommendation available.

Properties

  • Variable self-assembly system
  • Good flow characteristics
  • Aluminium cog wheels can be used either inside or outside
  • High stability
  • Temperature resistance up to 80 °C
  • Plastic parts with temperature resistance up to +180°C (short-term) upon request
  • Lamella W-01-S

    Lamella W-01-S

    • Art. no.: 320400011
    • Aluminum
    • Width 100 mm
    • Length 5 m, PU 50 m
    Gebhardt-Stahl GmbH
  • Lamella W-01-G with retainer for rubber seal

    Lamella W-01-G with retainer for rubber seal

    • Art. no.: 320400010
    • Aluminum
    • Width 100 mm
    • With retainer for rubber seal
    • Length 5 m, PU 50 m
    Gebhardt-Stahl GmbH
  • Side part

    Side part

    • Art. no.: 320400030
    • Galvanised steel, 1,2 mm
    • Width 175 mm
    • For Aluminium lamellas 100mm
    • Length 3 m
    • PU 1pc
    Gebhardt-Stahl GmbH
  • Cog wheel W-01

    Cog wheel W-01

    • Art. no.: 320400020
    • Aluminum
    • For Aluminium lamellas 100mm
    • PU 100 pcs
    Gebhardt-Stahl GmbH
  • Bearing cap - (L)

    Bearing cap - (L)

    • Art. no.: 320400040
    • Color: black
    • Polyamide
    • PU 100 pcs
    Gebhardt-Stahl GmbH
  • Bearing cap - (R)

    Bearing cap - (R)

    • Art. no.: 320400050
    • Color: black
    • Polyamide
    • PU 100 pcs
    Gebhardt-Stahl GmbH
  • End cap

    End cap

    • Art. no.: 320400060
    • Color: black
    • Polyamide
    • PU 100 pcs
    Gebhardt-Stahl GmbH
  • Bearing part

    Bearing part

    • Art. no.: 320400070
    • Color: black
    • Polyamide
    • PU 100 pcs
    Gebhardt-Stahl GmbH
  • Drill screw 4,2x42mm

    Drill screw 4,2x42mm

    • Art. no.: 317035020
    • Galvanised steel
    • PU 1.000 pcs
    Gebhardt-Stahl GmbH
  • Axle

    Axle

    • Art. no.: 320370010
    • Galvanised steel
    • 10 x 10 mm, length 150 mm
    • PU 50 pcs
    Gebhardt-Stahl GmbH
  • Rubber seal for W-01-G

    Rubber seal for W-01-G

    • Art. no.: 320400080
    • For Lamella „W-01-G“
    • Color: black
    • PU 400 m
    Gebhardt-Stahl GmbH
  • Stopper seal

    Stopper seal

    • Art. no.: 320190010
    • Color: black
    • PU 100 m
    Gebhardt-Stahl GmbH
  • Hand locking lever 10 x 10 mm

    Hand locking lever 10 x 10 mm

    • Art. no.: 320300000
    • Galvanised steel
    • For axle 10 x 10 mm
    • PU 10 pcs
    Gebhardt-Stahl GmbH
  • Locking lever

    Locking lever

    • Art. no.: 320100010
    • For lamella
    • PU 10 pcs
    Gebhardt-Stahl GmbH
  • Ball joint M8

    Ball joint M8

    • Art. no.: 320100020
    • For hand locking lever
    • PU 10 pcs
    Gebhardt-Stahl GmbH
  • Threaded rod M8

    Threaded rod M8

    • Art. no.: 314130010
    • Galvanised steel
    • Length 1m
    • PU 50 pcs
    Gebhardt-Stahl GmbH
